1.INDUSTRY CHALLENGE

In metal fabrication, press brakes are indispensable—yet traditional asynchronous motor-driven systems struggle with modern demands for precision, efficiency, and energy savings. Chnchi  Electric’s ZE25 Series 90kW Servo Motor and MZ650 Pulse-Type Servo Drive deliver a breakthrough upgrade solution.

 2.PROJECT OVERVIEW

We transformed a customer’s asynchronous motor-driven press brake into a high-performance servo-controlled system, achieving:

30% higher cutting accuracy

50% faster production cycles

20% energy reduction

3.TECHNICAL IMPLEMENTATION

（1）Hardware Selection

- Servo Motor:

  ZE25 Series 90kW motor provides high dynamic response and superior torque control for razor-sharp cuts.

- Servo Drive:

  MZ650 Pulse Drive offers plug-and-play tuning and robust motion control, perfectly synced with the motor.

（2）System Integration

- Conducted full mechanical/electrical compatibility assessment.

- Upgraded legacy wiring and seamlessly integrated servo drives with the brake’s control system.

（3）Calibration & Testing

- Fine-tuned speed, acceleration, and positioning parameters for optimal performance.

- Ran multi-material thickness tests to ensure consistent, burr-free cuts.

4.TANGIBLE RESULTS

Precision

Closed-loop servo control reduced cutting errors by 30%, even with complex geometries.

Productivity

50% faster cycle times thanks to the servo’s instant torque response—ideal for high-volume jobs.

Energy Efficiency

20% lower power consumption, especially during idle/low-load states, cutting operational costs.

---

 CUSTOMER VERIFIED

After months of operation, the client confirmed:

- Long-term cost savings from reduced energy.

- Unmatched consistency in mass production.
