I. SERVO SYSTEM REQUIREMENTS FOR LASER CUTTING MACHINES

Laser cutting machines place stringent demands on servo systems. During operation, they require:

- High-precision positioning and rapid movement control of the cutting head to ensure accurate cutting paths and optimal efficiency

- Exceptional stability and dynamic response to maintain precision during high-speed operation

- Wide power output range and flexible parameter adjustment capabilities to accommodate different materials and thicknesses

The servo system must deliver micron-level positioning accuracy while maintaining stability during rapid acceleration/deceleration and directional changes.

II. ADVANTAGES OF CHNCHI'S SERVO SOLUTIONS

(1) ZE Series Servo Motors

Power Matching

- Available in 400W and 750W configurations to meet diverse cutting demands

- 400W motors ensure precision for thin materials

- 750W motors provide powerful cutting performance for thick materials/high speeds

Precision Control

- High-quality encoders and precision motor design enable micron-level positioning accuracy

- Ensures cutting head follows programmed paths with minimal deviation

Dynamic Response

- Excellent acceleration/deceleration performance (0-3000 RPM in milliseconds)

- Instant response to direction/speed changes maintains cutting continuity

(2) MZ860 Series Servo Drives

High-Performance Drive

- Advanced control algorithms ensure stable, powerful current output

- Maintains optimal performance across all operating conditions

Flexible Configuration

- Adjustable parameters (speed loop, position loop, torque compensation, etc.)

- Enables customization for specific cutting applications

Intelligent Protection

- Built-in safeguards (overcurrent/overvoltage/overtemperature protection)

- Prevents equipment damage and extends service life

III. APPLICATION RESULTS

(1) Enhanced Cutting Precision

- Positioning accuracy improved by 30-50% compared to conventional systems

- Achieves ±0.01mm repeat positioning accuracy

- Enables finer, more intricate cutting patterns

(2) Increased Productivity

- Cutting speed increased by 20-35% while maintaining quality

- Reduces cycle times for thick materials/complex patterns

- Maximizes equipment utilization rates

(3) Improved System Reliability

- 99.5%+ uptime in continuous operation

- 50% reduction in motion-related failures

- Stable performance even in 24/7 production environments

CONCLUSION

The successful application of Chnchi's ZE series motors and MZ860 drives in laser cutting systems demonstrates our technical expertise in servo technology development. These solutions have proven capable of:

- Meeting the most demanding precision requirements

- Delivering measurable productivity gains

- Ensuring long-term operational reliability

As a leading motion control specialist, Chnchi remains committed to technological innovation, continually developing advanced solutions for industrial automation. We look forward to empowering more manufacturers with our high-performance servo products.
